Invasion Dynamics

Smithsonian marine biologists and colleagues at Temple University tested predictions about biological invasions, first in Panama and then in an experiment of unprecedented geographic scale.


From Refuge Cove in Alaska to San Francisco Bay to Baja California and at the Pacific entrance to the Panama Canal, a team from the Smithsonian Tropical Research Institute and Temple University deployed panels to find out what limits marine invertebrate invasions. Here, Laura Jurgens and Carmen Schloeder, celebrate a successful deployment in Mexico (Laura Jurgens)
From Refuge Cove in Alaska to San Francisco Bay to Baja California and at the Pacific entrance to the Panama Canal, a team from the Smithsonian Tropical Research Institute and Temple University deployed panels to find out what limits marine invertebrate invasions. Here, Laura Jurgens and Carmen Schloeder, celebrate a successful deployment in Mexico (Laura Jurgens)

Night and day, oil tankers, yachts and cargo ships stacked with shipping containers ply the 80-kilometer (50-mile) waterway through the jungles of Panama between the Atlantic and the Pacific Ocean: about 40 ships every 24 hours. But even though the Canal is fed by freshwater rivers that empty through the locks on each end, a system that generally prevents fish and smaller marine invertebrates from hopping from ocean to ocean, some still manage to get through, clinging to the hulls of ships. Other invading species arrive from far-flung ports, dumped with ballast water as ships prepare for transit.

“Panama is a major shipping hub that provides amazing opportunities to test key ideas about marine invasions by studying two very different oceans at the same latitude,” said Mark Torchin, staff scientist at the Smithsonian Tropical Research Institute (STRI), “I can check sites in the ocean in front of my lab at the Pacific entrance to the Canal and then drive to the Atlantic coast in an hour to check sites there. Where else in the world can you do that?”

Mark Torchin and Carmen Schloeder
Mark Torchin, staff scientist at the Smithsonian Tropical Research Institute (STRI) and research manager, Carmen Schloeder, harvesting a sample of marine invertebrates in Panama. Sean Mattson, STRI

Since the Canal opened in 1914, the human population of the world has catapulted from 2 billion to almost 8 billion. And as people move around the globe, other organisms move as well. Fish breeders in the United States imported carp from Asia to clean their ponds; now Asian Carp have worked their way up the Mississippi River system to Canada, destroying natural bird and fish habitat along the way. Likewise, cane toads were introduced in Australia to control beetles, but because they have no natural predators there, toad numbers exploded. But most invasions are inadvertent, as animals (or viruses, for that matter) hitch rides on boats or planes.

“We have very practical reasons to test ideas about the success of invaders in different locations as we learn how to predict and manage invasions,” said Amy Freestone, associate professor at Temple University and research associate at both STRI in Panama and the Smithsonian Environmental Research Center (SERC) in Maryland. “With these paired experimental studies, we wanted to know if marine invaders are equally successful in all environments and how important predators are to keep them in check.”

First the team asked whether marine invaders are more successful in one ocean basin compared to the other. Is the proportion of non-native species higher in the less-diverse Pacific compared to the more-diverse Atlantic as theory predicts? And is there asymmetrical exchange between oceans in Panama, with more species introduced from the Atlantic to Pacific than in the opposite direction?

To find out, they suspended PVC panels as habitat patches for colonization. About the size of patio tiles, panels were placed in the water at 10 different sites near each end of the Panama Canal. They waited for 3 months for marine invertebrates to colonize the panels. Then they removed these standard collectors, photographed the results and identified the species on the panels, classifying them as either native, non-native or species of unknown origin.

They found more non-native species in the less-diverse Pacific where there were 18 non-native species, 30% of all Pacific species, than in the more-diverse Atlantic where there were 11 non-native species, 13% of all Atlantic species. And there was a higher influx of invaders from the Atlantic to the Pacific than vice versa.

Michele Repetto
Michele Repetto, co-author from Temple University (light blue shirt) recording observations of a panel which has been in the water for 3 months, hanging from a dock near the Atlantic end of the Panama Canal. She weighs the panels and, to catch predators in action, will equip one of the panels with a GoPro camera and lower it into the water, where it will stay for several hours. Ana Endara, STRI
None
Atlantic and Pacific panels
Atlantic panel (above) and Pacific panel (below). Researchers suspended panels in the ocean on the Atlantic and Pacific sides of Panama for 3 months, face down in the water, to collect invertebrates. In general, the Pacific panels collected fewer invertebrates than panels placed on the Atlantic side of Panama. Carmen Schloeder, STRI

Along the way they reported 9 new non-native sessile invertebrates in the Pacific and 7 in the Atlantic that were previously unknown from these areas. One of the important contributions of this project was a collaboration with the Panama Canal Authority (Autoridad del Canal de Panama, ACP) and the Panama Maritime Authority (Autoridad Maritima de Panama, AMP), with support from Panama’s Secretariat for Science and Technology (SENACYT) to create an online database called Pan-NEMO of non-native species as part of the National Estuarine and Marine Exotic Species Information System (NEMESIS).

The team also combed through previous scientific papers, pulling together the cumulative record of all non-native marine species reported to date in Panama. They found the same thing: eight times more non-native species were reported from the Pacific than from the Atlantic in this area.

Next they looked for evidence of a concept called biotic resistance, the idea that, in biodiverse environments, it is harder for invaders to gain a foothold because they have to compete with the natives and survive alongside native predators. To test effects of predators, they compared caged and uncaged panels in two companion studies. They suspended uncovered panels, panels with mesh cages to keep predators out, and panels with mesh along the sides but open at one end at 3 sites per ocean, waited three months, and then identified the invertebrates and weighed them.

panel set-up
To find out if predation changes the composition of the community of invertebrates, researchers enclosed some of the panels with a mesh cage. On the Pacific side of Panama, predation was greater than on the Atlantic side, and some species were only found in enclosed panels on the Pacific, rarely on open panels. Predation was also greater in the tropics than further north. The results of this study indicate that conserving the biodiversity of a site and protecting the predators may limit marine invasions. STRI

Predation substantially reduced biomass and changed non-native species composition in the Pacific, but not on the Atlantic coast. Some of the dominant non-native species were particularly susceptible to predation in the Pacific, supporting the hypothesis that predation reduces the abundance of certain non-native species.

Based on the results of the Panama experiments the research team secured funding from the US National Science Foundation to also test the idea that predation is stronger the closer you get to the equator and to find out how it impacts communities of marine invertebrates. To do this, they put out PVC panels, with and without cages at 12 sites in 4 regions: subarctic, Ketchikan, Alaska; temperate, San Francisco, California; subtropical La Paz, Mexico and tropical Panama City, Panama.

Team in Mexico
The team compared panels with and without predators at three sites in each of four regions: subarctic (Alaska), temperate (San Francisco, CA), subtropical (Mexico) and tropical (Panama). IAmy Freestone, Marina Bonfim, Diana Lopez, Michele Repetto, in Mexico. Greg Ruiz, SERC

“These projects not only provide interesting data,” said Carmen Schloeder, research manager in the Torchin lab and co-author of both studies, “but also a great experience working for extended periods of time in different environments with collaborators from many different cultural backgrounds. I’m proud to be part of a diverse core team which includes many women: to be able to work with and learn from inspiring colleagues is an essential part of science. “

Results of the second experiment showed that indeed, predators closer to the equator were more diverse, predation rates were higher, predators were larger and they spent more time interacting with their prey. Predation is a much more important force in the tropics than further north. In the tropics, the effects of predators were obvious: they reduced the biomass on the plates and changed the composition of the organisms. In the North, this didn’t happen. Communities of marine invertebrates are hit harder by predators in the tropics.

Fish Predation on Marine Invertebrates / Depredación de peces en invertebrados marinos

“We show that predators are a critical component of these marine ecosystems, particularly in the tropics, and can limit the abundance of introduced species,” Freestone said. “Protect the predators—that is, protect these diverse environments—and you are protecting the world’s oceans from invasions by species that may radically alter the balance of marine ecosystems.”

“Healthy ecosystems resist invasions,” said Gregory Ruiz from the Smithsonian Environmental Research Center (SERC). “Along with global efforts to reduce organism transfers by ships, conservation of native predator populations plays a critical role in biosecurity to prevent new invasions.”

The Smithsonian Tropical Research Institute, headquartered in Panama City, Panama, is a unit of the Smithsonian Institution. The institute furthers the understanding of tropical biodiversity and its importance to human welfare, trains students to conduct research in the tropics and promotes conservation by increasing public awareness of the beauty and importance of tropical ecosystems. Promo video.

References:

Torchin, M.E., Freestone, A.L., McCann, L. et al. Asymmetry of marine invasions across tropical oceans. Ecology. https://doi.org/10.1002/ecy.3434

Freestone, A.L., Torchin, M.E., Jurgens et al. 2021. Stronger predation intensity and impact on prey communities in the tropics. Ecology. https://doi.org/10.1002/ecy.3428

Fofonoff PW, Ruiz GM, Steves B, Simkanin C, Carlton JT, Schlöder C & Torchin ME. 2017. Panama Non-native Estuarine and Marine Organisms (Pan-NEMO) System. https://invasions.si.edu/nemesis/Panama
