What the Image of the Milky Way’s Black Hole Really Shows

Black holes keep their secrets close. They imprison forever anything that enters. Light itself can’t escape a black hole’s hungry pull.

It would seem, then, that a black hole should be invisible — and taking its picture impossible. So great fanfare accompanied the release in 2019 of the first image of a black hole. Then, in spring 2022, astronomers unveiled another black hole photo — this time of the one at the center of our own Milky Way.

The image shows an orange, donut-shaped blob that looks remarkably similar to the earlier picture of the black hole in the center of galaxy Messier 87. But the Milky Way’s black hole, Sagittarius A*, is actually much smaller than the first and was more difficult to see, since it required peering through the hazy disk of our galaxy. So even though the observations of our own black hole were conducted at the same time as M87’s, it took three additional years to create the picture. Doing so required an international collaboration of hundreds of astronomers, engineers and computer scientists, and the development of sophisticated computer algorithms to piece together the image from the raw data.

These “photos” do not, of course, directly show a black hole, defined as the region of space inside a point-of-no-return barrier known as an event horizon. They actually record portions of the flat pancake of hot plasma swirling around the black hole at high speeds in what’s known as the accretion disk. The plasma is composed of high-energy charged particles. As plasma spirals around the black hole, its accelerating particles emit radio waves. The blurry orange ring seen in the images are an elaborate reconstruction of these radio waves captured by eight telescopes scattered around the Earth, collectively known as the Event Horizon Telescope (EHT).

The latest image tells the tale of the epic journey of radio waves from the center of the Milky Way, providing unprecedented detail about Sagittarius A*. The image also constitutes “one of the most important visual proofs of general relativity,” our current best theory of gravity, says Sera Markoff, an astrophysicist at the University of Amsterdam and member of the EHT collaboration.

Studying supermassive black holes such as Sagittarius A* will help scientists learn more about how galaxies evolve over time and how they congregate in vast clusters across the universe.

From the galactic core

Sagittarius A* is 1,600 times smaller than Messier 87’s black hole that was imaged in 2019, and is also about 2,100 times closer to Earth. That means the two black holes appear to be about the same size on the sky. Geoffrey Bower, an EHT project scientist at the Academia Sinica Institute of Astronomy and Astrophysics in Taiwan, says that the resolution required to see Sagittarius A* from Earth is the same as would be required to take a picture of an orange on the surface of the Moon.

The center of our galaxy is 26,000 light-years away from us, so the radio waves collected to create this image were emitted around the time that one of the earliest-known permanent human settlements was constructed. The radio waves’ voyage began when they were first emitted from particles in the black hole’s accretion disk. With a wavelength of about 1 mm, the radiation traveled toward Earth relatively undisturbed by the intervening galactic gas and dust. If the wavelength were much shorter, like visible light, the radio waves would have been scattered by the dust. If the wavelength were much longer, the waves would have been bent by charged clouds of plasma, distorting the image.

Finally, after the 26,000-year trek, the radio waves were picked up and recorded at the radio observatories distributed across our planet. The large geographic separation between the observatories was essential — it allowed the consortium of researchers to detect extremely subtle differences in the radio waves collected at each site through a process called interferometry. These small differences are used to deduce the minuscule differences in the distance each radio wave traveled from its source. Using computer algorithms, the scientists managed to decode the path-length differences of the radio waves to reconstruct the shape of the object that emitted them.

Researchers put all this into a false-color image, where orange represents high-intensity radio waves and black represents low-intensity. “But each telescope only picks up a tiny fraction of the radio signal,” explains Fulvio Melia, an astrophysicist at University of Arizona who has written about our galaxy’s supermassive black hole. Because we’re missing much of the signal, “instead of seeing a crystal clear photo, you see something that’s a little foggy … a little blurred.”

The image helps reveal more about the black hole’s event horizon — the closest point to which anything can approach the black hole without being sucked in. Beyond the event horizon, not even light can escape.

From the image, scientists have been able to better estimate the size of the event horizon and deduce that the accretion disk is tilted by more than 40 degrees from the Milky Way’s disk, so that we’re seeing the round face of the flat accretion disk, rather than the thin sliver of its edge.

But even if the black hole’s accretion disk were oriented edge-on relative to Earth, the gravity around the black hole warps the space around it so much that light emitted from the backside of the black hole would be bent around to come toward us, making a ringlike image regardless of its orientation. So, how do scientists know its orientation? Because the ring is mostly round; if we were viewing the accretion disk edge-on, then the ring would be more squished and oblong.

Markoff thinks that this new ability to look into the heart of our galaxy will help to fill in gaps in our understanding of the evolution of galaxies and the large-scale structure of the universe. A dense, massive object such as a black hole at the center of a galaxy influences the movements of the stars and dust near it, and that influences how the galaxy changes over time. Properties of the black hole, such as in which direction it spins, depend on the history of its collisions — with stars or other black holes, perhaps. “A lot of people … look at the sky and think of it all as static, right? But it’s not. It’s a big ecosystem of stuff that’s evolving,” Markoff says.

So far, the fact that the image matches the scientists’ expectations so precisely makes it an important confirmation of current theories of physics. “This has been a prediction that we’ve had for two decades,” Bower says, “that we would see a ring of this scale. But, you know, seeing is believing.”
